Group Objects Description
1 Fault information
If group object #3 ”fault transmission” is set to “on”, the following faults can be transmitted if they
occur. In that case, group object #2 value changes to “alarm”.
Error Group obj. #1 Description Resolution
Device jammed XX 00 0A 03 0C 05 Target position can’t be
reached due to blockage.
Remove blockage (visual
inspection required) or
invert Opening direction,
if it is set wrongly
Or switch on adaptive
positioning, if mechanical
limits are intended.
Backup mode
entered
XX 01 01 02 0C 05
Actuator is in backup mode
(cf. respective parameter
setting)
Actuator leaves Backup
mode when receiving a
setpoint.
Operating hours
notification
XX 01 0A 04 0C 05
Appears after a cumulated
motor running time of 365
days
Check device status and
control loop sensitivity
2 Fault state Indicates whether the actuator is in fault state. If yes, read out group object #1.
3 Fault transmission
Enabling/ disabling the fault transmission. Fault transmission is disabled by default; therefore no
faults are transmitted from the actuator over the KNX bus.
4
Setpoint position /
Setpoint pos. heating
1)
Setpoint 0…100% for valve position, depending on the operating mode.
5 Actual position /
Actual pos.heating
1)
Actual value 0…100% for valve position, depending on the operating mode.
6 Setpoint pos. cooling
1)
Setpoint 0…100% for valve position, available in operating mode “Heating / cooling control”.
7 Actual pos. cooling
1)
Actual value 0…100% for valve position, available in operating mode “Heating / cooling control”.
8 Fault Same function as group object #2 (available for compatibility reasons).
9 Override position 1
When the object is triggered, the actuator drives to the override position 1 defined by the respective
ETS parameter.
10 Override position 2
When the object is triggered, the actuator drives to the override position 2 defined by the respective
ETS parameter.
