Item Brochure

Technical specifications
Overview
System Description
Semi-automated urine chemistry analyzer
Tests Measured
Leukocyte, Nitrite, Protein, Blood, Glucose, Ketone,
Bilirubin, Urobilinogen, pH, Specific Gravity, Creatinine,*
and Protein-to-Creatinine Ratio*
Automatic Measurement
Urine color
Test Format
Dry chemistry reagent strips
Test Measurement
Color change measured by reflectance photometry
Dual readings at reactive and reference wavelengths
Automatically adjusts for urine color
General
Dimensions
12.75 (h) x 15.75 (w) x 13.75 (d) in,
32 (h) x 39 (w) x 35 (d) cm
Weight
7.2 kg (16 lbs)
Power Requirements
100 V to 240 V; 50/60 Hz
Line Leakage Current
<0.5 mA in normal condition
<3.5 mA in single fault condition
Maximum Power Input
72 VA
Ambient Operating
Temperature Range
18oC to 30oC (64oF to 86oF)
Ambient Operating Humidity
Range
20% to 80% relative humidity
Compliance
UL, CE, EMC
Test Handling
Sample Loading
Self-paced, not dictated by analyzer
STAT Sample Handling
One-touch STAT interrupt capability
Sample Processing
Single or batch mode
Sample ID Entry
Manual, bar code, or downloaded from LIS
Calibration
Calibration
Automatic with every strip
Onboard Computer
Memory
500 patient records plus 200 controls
Interfaces
ASTM (CCS) format and emulates Clinitek200 and Clinitek
200+
Display
Color LCD touch screen, 5.7 in (14.5 cm), 320 horizontal
by 240 vertical pixels (QVGA)
Computer/Peripheral
Interfaces
Ethernet Connection
10/100 Mbit, bidirectional
Onboard Printer
24-character thermal printer
Bar Code
Meets ASTM E1466-92 standards, available with PC
wedge/PS2 connection
Keyboard
External PC keyboard option/PS2 connection
External Printer
Printer interface: parallel port connector (25 pin)
