Remote operation

7.2 Operating via FDT

SITRANS LR250 (PROFIBUS PA)

Operating Instructions, 01/2014, A5E32221386-AB

7.2.3

The device EDD

The SITRANS LR250 PROFIBUS PA EDD for SITRANS DTM can be downloaded from our

website:

Product page (http://www.siemens.com/LR250

Go to

Support > Software Downloads

7.2.4

Configuring a new device via FDT

The full process to configure a field device via FDT is outlined in an Application Guide which can

be downloaded from our website under

Support

> Application Guides

Product page (http://www.siemens.com/LR250)
