Remote operation

7.1 Operating via SIMATIC PDM

SITRANS LR250 (PROFIBUS PA)

Operating Instructions, 01/2014, A5E32221386-AB

7.1.5.11

Diagnostics

You can monitor level/volume trends, function blocks, electronics temperature, and device

status.

Process variables

To compare outputs in real time open the menu

View

–

Process Variables

Note

To view peak sensor values, peak FB

1 and FB2 values, or peak electronics temperatures,

see

Device Diagnostics (Page 86).

● Sensor Value and simulation setting

● Electronics temperature

● Measured Value (level, volume, and distance) together with quality and status.
