Remote operation

7.1 Operating via SIMATIC PDM

SITRANS LR250 (PROFIBUS PA)

62 Operating Instructions, 01/2014, A5E32221386-AB

5. After the reset is complete click on

, then upload parameters to the PC/PG.

6. Configure the device via the Quick Start wizard.

7.1.3

Quick start wizard via SIMATIC PDM

The graphic Quick Start Wizard provides an easy step-by-step procedure that configures the

device for a simple application.

Please consult the operating instructions or online help for details on using SIMATIC PDM.

1. If you have not already done so, check that you have the most up-to-date Electronic Device

Description (EDD) for your device. [See Configuring a new device (Page 61).]

2. Launch SIMATIC Manager and create a new project. Application Guides for setting up HART

and PROFIBUS PA devices with SIMATIC PDM can be downloaded from the product page of

our website:

Product page (http://www.siemens.com/LR250

)
