Remote operation

7.1 Operating via SIMATIC PDM

SITRANS LR250 (PROFIBUS PA)

60 Operating Instructions, 01/2014, A5E32221386-AB

7.1.1.1

Features of SIMATIC PDM Rev. 6.0, SP4 or higher

The graphic interface in the device makes monitoring and adjustments easy.

Feature

Function

Quick Start (Page 62)

Device configuration for simple applications

Echo Profile Utilities (Page 69)

Easy access to echo profile viewing/comparison, TVT shaping,

auto false echo suppression and echo setup

Auto False Echo Suppression

(Page 73)

Screen out false echoes

TVT Shaper (Page 72)

Manual TVT adjustment

Process Variables (Page 83)

Monitor process variables and level trend

Security (Page 89)

Protect security and communication parameters from

modification by the maintenance user

7.1.1.2

Features of SIMATIC PDM Rev. 5.2, SP1

SIMATIC PDM Rev. 5.2 SP1 is supported only for basic configuration and troubleshooting. For

advanced features such as the Quick Start wizard, Rev. 6.0 SP3 HF2 or higher is required.

7.1.1.3

SIMATIC PDM Version

Check the support page of our website to make sure you have the latest version of SIMATIC

PDM, the most recent Service Pack (SP) and the most recent hot fix (HF): SIMATIC PDM

Version (https://support.automation.siemens.com

). Browse to

Product Information > Automation

Technology > Process control systems > SIMATIC PCS 7 > System components > SIMATIC

PDM.
