6.1 Operating via the handheld programmer

SITRANS LR250 (PROFIBUS PA)

Operating Instructions, 01/2014, A5E32221386-AB

6.1.3.7

Device address

Note

See

Master Reset (Page 82) to reset Device Address to 126.

The unique address of the device on the network (also called PROFIBUS address).

Values

0 - 126. Default: 126

1. In PROGRAM mode, navigate to:

Level Meter > (5.)

Communication > (5.1.)

Device Address

2. Press

RIGHT arrow

, to open parameter view and enable Edit mode.

3. If required, key in a new value and press

RIGHT arrow

to accept it. The LCD displays the

new value.

4. Press

Mode

to return to Measurement mode.
