Commissioning

6.1 Operating via the handheld programmer

SITRANS LR250 (PROFIBUS PA)

Operating Instructions, 01/2014, A5E32221386-AB

1.6 Low Calibration Point

Distance from Sensor Reference to Low Calibration Point: usually process empty level. (See

Operating mode

for an illustration.)

Values

Range: 0.00 to 20.00 m

1.7 High Calibration Point

Distance from Sensor reference point to High Calibration Point: usually process full level. (See

Operating

mode

for an illustration.)

Values

Range: 0.00 to 20.00 m

1.8 Apply? (Apply changes)

Options

YES, NO, DONE (Display shows DONE when Quick Start is successfully

completed.)

Press

Mode

to return to

Measurement

mode. SITRANS LR250 is now ready to operate.

6.1.3.5

Auto False Echo Suppression

If you have a vessel with known obstructions, we recommend using Auto False Echo

Suppression to prevent false echo detection. See

(2.5.10.) TVT setup

for instructions.

This feature can also be used if the display shows a false high level, or the reading is fluctuating

between the correct level and a false high level.
