Commissioning

6.1 Operating via the handheld programmer

SITRANS LR250 (PROFIBUS PA)

Operating Instructions, 01/2014, A5E32221386-AB

6.1.3

Programming

Note

•

While the device is in PROGRAM mode the output remains active and continues to

respond to changes in the device.

•

The device automatically returns to Measurement mode after a period of inactivity in

PROGRAM mode (between 15 seconds and 2 minutes, depending on the menu level).

Change parameter settings and set operating conditions to suit your specific application. For

remote operation see Operating via SIMATIC PDM (Page 59).

Note

For the complete list of parameters with instructions, see

Parameter Reference (Page 93).

Parameters are identified by name and organized into function groups. See LCD menu structure

(Page 249).

1. QUICK START

2. SETUP

2.1. IDENTIFICATION

............

2.6. LINEARIZATION

2.6.1. VOLUME

2.6.1.1. VESSEL SHAPE
