SITRANS LR250 (PROFIBUS PA)
Legal information
Table of contents
1 Introduction
- 1.1 The manual
- 1.2 Firmware revision history
2 Safety notes
- 2.1 Safety marking symbols
- 2.2 FCC Conformity
- 2.3 CE Electromagnetic Compatibility (EMC) Conformity
3 Description
- 3.1 SITRANS LR250 overview
- 3.2 Programming
- 3.3 Applications
- 3.4 Approvals and certificates
4 Installing/mounting
- 4.1 Pressure applications
  - 4.1.1 Pressure Equipment Directive, PED, 97/23/EC
- 4.2 Mounting location
- 4.3 Installation instructions
- 4.4 Flange bolting, Flanged encapsulated antenna only
5 Connecting
- 5.1 Power
- 5.2 Connecting SITRANS LR250
  - 5.2.1 Basic PLC configuration with PROFIBUS PA
- 5.3 Wiring setups for hazardous area installations
- 5.4 Instructions specific to hazardous area installations
6 Commissioning
- 6.1 Operating via the handheld programmer
- 6.2 Application examples
7 Remote operation
- 7.1 Operating via SIMATIC PDM
- 7.2 Operating via FDT
8 Parameter reference
- 8.1 Alphabetical parameter list
9 Service and maintenance
- 9.1 Maintenance
- 9.2 Unit repair and excluded liability
- 9.3 Part replacement
10 Diagnosing and troubleshooting
- 10.1 Device status icons
- 10.2 General fault codes
- 10.3 Operation troubleshooting
11 Technical data
- 11.1 Power
- 11.2 Performance
- 11.3 Interface
- 11.4 Mechanical
- 11.5 Environmental
- 11.6 Process
- 11.7 Approvals
- 11.8 Programmer (infrared keypad)
12 Dimension drawings
- 12.1 Threaded horn antenna
- 12.2 Threaded horn antenna with extension
- 12.3 Flanged horn antenna
- 12.4 Flanged horn antenna with extension
- 12.5 Flanged encapsulated antenna (2"/DN50/50A sizes only)
- 12.6 Flanged encapsulated antenna (3"/DN80/80A sizes and larger)
- 12.7 Threaded PVDF antenna
- 12.8 Threaded connection markings
- 12.9 Raised-Face flange per EN 1092-1 for flanged horn antenna
- 12.10 Raised-Face flange per EN 1092-1 for flanged encapsulated antenna
- 12.11 Flat-Face flange
- 12.12 Process connection tag (pressure rated versions)
A Appendix A: Technical reference
- A.1 Principles of operation
- A.2 Echo processing
- A.3 Maximum Process Temperature Chart
- A.4 Process Pressure/Temperature Derating Curves
B Appendix B: PROFIBUS PA profile structure
- B.1 PROFIBUS Level Device Design
- B.2 Block Model
C Appendix C: Communications via PROFIBUS
- C.1 Device configuration
  - C.1.1 SIMATIC PDM
  - C.1.1.1 Electronic Device Description
- C.2 Network configuration
  - C.2.1 The GSD file
- C.3 Bus termination
- C.4 Power demands
- C.5 PROFIBUS address
- C.6 Operating as a profile device
  - C.6.1 Configuring a new device
  - C.6.2 Configuring PROFIBUS PA with an S7-300/ 400 PLC
- C.7 Cyclic versus acyclic data
  - C.7.1 Cyclic data
- C.8 Status byte
- C.9 Condensed status
- C.10 Diagnostics
D Appendix D: Certificates and Support
- D.1 Certificates
- D.2 Technical support
13 List of abbreviations
14 LCD menu structure
Glossary
Index

Connecting

5.3 Wiring setups for hazardous area installations

SITRANS LR250 (PROFIBUS PA)

Operating Instructions, 01/2014, A5E32221386-AB

Entity concept:

The Entity Concept allows interconnection of intrinsically safe apparatus to associated apparatus

not specifically examined in such combination. The criteria for interconnection is that the voltage

and current which intrinsically safe apparatus can receive and remain intrinsically safe,

considering faults, must be equal to or greater than the output voltage (Uo) and output current

(Io) levels which can be delivered by the associated apparatus, considering faults and applicable

factors. In addition, the maximum unprotected capacitance (Ci) and Inductance (Li) of the

intrinsically safe apparatus, including interconnecting wiring, must be equal to or less than the

capacitance and inductance which can be safely connected to associated apparatus.

Under the entity evaluation concept, SITRANS LR250 has the following characteristics:

(input voltage) U

= 24 V

(input current) I

= 250 mA

(input power) P

= 1.2 W

(internal capacitance) Ci

= 0

(internal inductance) Li

= 0
