Connecting

5.2 Connecting SITRANS LR250

SITRANS LR250 (PROFIBUS PA)

Operating Instructions, 01/2014, A5E32221386-AB

Wiring instructions

1. Strip the cable jacket for approximately 70 mm (2.75") from the end of the cable, and thread

the wires through the gland. (If cable is routed through conduit, use only approved suitable-

size hubs for waterproof applications.)

2. Connect the wires to the terminals as shown: the polarity is identified on the terminal block.

3. Ground the device according to local regulations.

4. Tighten the gland to form a good seal.

5. Close the lid and secure the locking screw before programming and device configuration.

Note

•

PROFIBUS PA cable shield must be terminated at both ends of the cable for it to work

properly.

•

If a Weidmüller or other current limiting junction box is connected to this device, please

ensure that the current limit is set to 40 mA or higher.

•

Please refer to the PROFIBUS PA User and Installation Guidelines (order number 2.092)

for information on installing PROFIBUS devices at:

PROFIBUS PA (

http://www.profibus.com/)
