Safety notes
2.3 CE Electromagnetic Compatibility (EMC) Conformity
SITRANS LR250 (PROFIBUS PA)
12 Operating Instructions, 01/2014, A5E32221386-AB
2.3
CE Electromagnetic Compatibility (EMC) Conformity
This equipment has been tested and found to comply with the following EMC Standards:
EMC Standard
Title
CISPR 11:2004/EN
55011:1998+A1:1999&A2:2002, CLASS B
Limits and methods of measurements of radio
disturbance characteristics of industrial,
scientific, and medical (ISM) radio-frequency
equipment.
EN 61326:1997+A1:1998+A2:2001+A3:2003
(IEC 61326:2002)
Electrical Equipment for Measurement, Control
and Laboratory Use – Electromagnetic
Compatibility.
EN61000-4-2:2001 Electromagnetic Compatibility (EMC) Part 4-
2:Testing and measurement techniques –
Electrostatic discharge immunity test.
EN61000-4-3:2002 Electromagnetic Compatibility (EMC) Part 4-3:
Testing and measurement techniques –
Radiated, radio-frequency, electromagnetic
field immunity test.
EN61000-4-4:2004 Electromagnetic Compatibility (EMC) Part 4-4:
Testing and measurement techniques –
Electrical fast transient/burst immunity test.
EN61000-4-5:2001 Electromagnetic Compatibility (EMC) Part 4-5:
Testing and measurement techniques – Surge
immunity test.
EN61000-4-6:2004 Electromagnetic Compatibility (EMC) Part 4-6:
Testing and measurement techniques –
Immunity to conducted disturbances, induced
by radio-frequency fields.
EN61000-4-8:2001 Electromagnetic Compatibility (EMC) Part 4-8:
Testing and measurement techniques – Power
frequency magnetic field immunity test.
