Remote operation
7.1 Operating via AMS Device Manager
SITRANS LR250 (FOUNDATION FIELDBUS)
Operating Instructions, 01/2014, A5E32221411-AB
93
7.1.10
Configure/Setup (Liquid Crystal Display Block-LCD)
7.1.10.1
Identification (LCD)
Navigate to
Configure/Setup > LCD > Identification
.
Identification:
● TAG
● Descriptor
● Transducer Block Type
● Strategy
● Plant Unit
Note
For descriptions of Identification parameters see
Identification (LTB) (Page 77).
