Remote operation
7.1 Operating via AMS Device Manager
SITRANS LR250 (FOUNDATION FIELDBUS)
84 Operating Instructions, 01/2014, A5E32221411-AB
7.1.9.5
Signal processing
Signal Processing (LTB)
Note
For more detailed ex
planations of the parameters listed below see the pages referenced.
General
Navigate to
Configure/Setup > LTB > Setup > Signal Processing
and click on General for access
to:
Range
[see
Signal Processing (2.5.)
]
● Near Range [see
Near Range (2.5.1.)
]
● Far Range [see
Far Range (2.5.2.)
]
● Propogation Factor [see
Propogation Factor (2.5.3.)
]
● Minimum Sensor Value [see
Minimum Sensor Value (2.5.4.)
]
● Maximum Sensor Value [see
Maximum Sensor Value (2.5.5.)
]
