Remote operation
7.1 Operating via AMS Device Manager
SITRANS LR250 (FOUNDATION FIELDBUS)
70 Operating Instructions, 01/2014, A5E32221411-AB
7.1.6
Sensor calibration
The LR250 FF does not need to be calibrated, only configured using the Quick Start Wizard
below.
7.1.7
Configuring a new device
Configure a new device using the Quick Start Wizard, found in the
Resource Block
of the
function group
Configure/Setup
.
7.1.7.1
Quick Start Wizard via AMS Device Manager
The Quick Start Wizard groups together all the settings you need to configure a device for most
applications.
Please consult the operating instructions or online help for details on using AMS Device
Manager.
Note
Use Quick Start Wizard via AMS Device Manager for initial configuration of a device on an
FF network. If device is not on an FF network, initial configuration should be completed via
the Quic
k Start Wizard from the LUI. [See Quick Start Wizard via the handheld programmer
(Page
48).]
