Remote operation
7
7.1
Operating via AMS Device Manager
AMS Device Manager is a software package that monitors the process values, alarms and
status signals of the device. Please consult the operating instructions or online help for details
on using AMS Device Manager. You can find more information at:
Emerson (http://www.emersonprocess.com/AMS/
)
7.1.1
Functions in AMS Device Manager
Note
Do not use the handheld programmer at the same time as AMS Device Manager, or erratic
operation may result. To disable operation
via the handheld programmer, see
Local
Operation (6.2.3.).
AMS Device Manager can be used to monitor the process values, alarms and status signals of
the device. It allows you to display, compare, adjust, verify, and simulate process device data.
Configuration and monitoring of the device is completed via parameters organized into three
main function groups:
● Configure/Setup
● Device Diagnostics (read only)
● Process Variables (read only)
