Commissioning
6.2 Application examples
SITRANS LR250 (FOUNDATION FIELDBUS)
Operating Instructions, 01/2014, A5E32221411-AB
55
6.2
Application examples
Note
In the applications illustrated below, values are for example purposes only.
You can use these examples as setup references. Enter the values in the parameter tables to
select the corresponding functions.
Configure the basic settings using the Quick Start wizard parameters. (These parameters are
inter-related, and changes take effect only after you select
FINISH
in final step: Wizard
Complete.)
In each example, after performing a Quick Start, navigate to the other required parameters
(either via the handheld programmer or via AMS Device Manager) and enter the appropriate
values.
