Commissioning
6.1 Operating via the handheld programmer
SITRANS LR250 (FOUNDATION FIELDBUS)
Operating Instructions, 01/2014, A5E32221411-AB
45
3. Editing in PROGRAM mode
1. Navigate to the desired parameter.
2. Press
RIGHT
arrow
to open parameter view.
3. Press
RIGHT arrow
again to open
Edit
mode. The current selection is highlighted. Scroll
to a new selection.
4. Press
RIGHT arrow
to accept it. The LCD returns to parameter view and displays the new
selection.
①
Parameter name
②
Parameter number
③
Current selection
