Description
3.2 Programming
SITRANS LR250 (FOUNDATION FIELDBUS)
14 Operating Instructions, 01/2014, A5E32221411-AB
3.2
Programming
This device is very easy to install and configure via a graphical local user interface (LUI). You
can modify the built in parameters either locally via the Siemens infrared handheld programmer,
or from a remote location using one of the following options:
● FF host system
● AMS Device Manager
3.3
Applications
● liquids and slurries
● bulk storage vessels
● simple process vessels
3.4
Approvals and certificates
Note
For further details see
Approvals (Page 203).
SITRANS LR250 is available with General Purpose approval, or for hazardous areas. In all
cases, check the nameplate on your device, and confirm the approval rating.
Process Connections
A wide range of process connections and antenna options are available to suit virtually any
vessel configuration.
