SITRANS LR250 (FOUNDATION FIELDBUS)
Operating Instructions, 01/2014, A5E32221411-AB
9
Introduction
1
1.1
The manual
This manual will help you set up your radar device for optimum performance. For other Siemens
Milltronics level measurement manuals, go to:
Siemens level (http://www.siemens.com/level
)
Follow these operating instructions for quick, trouble-free installation, and maximum accuracy
and reliability of your device.
We always welcome suggestions and comments about manual content, design, and
accessibility. Please direct your comments to:
Technical publications (mailto:techpubs.smpi@siemens.com
)
Note
This manual applies to the SITRANS L
R250 (FOUNDATION™ Fieldbus) only.
FOUNDATION™ Fieldbus is a trademark of Fieldbus Foundation.
Application examples
The application examples used in this manual illustrate typical installations. [See Application
examples (Page 55).] Because there is often a range of ways to approach an application, other
configurations may also apply.
In all examples, substitute your own application details. If the examples do not apply to your
application, check the applicable parameter reference for the available options.
Note
For industrial use only
This product is intended for use in industrial areas. Operation of this equipment in a
residential area may ca
use interference to several frequency based communications.
