Remote operation
7.1 Operating via AMS Device Manager
SITRANS LR250 (FOUNDATION FIELDBUS)
Operating Instructions, 01/2014, A5E32221411-AB
101
Reset Type
Result
Factory Defaults
a)
Default. Resets all user parameters to the manufacturer’s default
settings. Following this type of reset, complete reprogramming is
required.
Standard Defaults
Resets all parameters to standard default settings.
Informational Resets parameters such as Block Descriptor, Strategy, Device
Install Date, Device Message.
Functional
a)
Resets parameters that control device behavior and functionality
(such as Low Calibration Point).
Warm Start
Has the same effect as recycling power to the device.
FF Object Dictionary Resets the FF standard block profile parameters (such as block
tags) to their specified defaults. This option also clears any function
block parameters and device schedule
b)
set by the user.
a)
The only difference between Factory Defaults and Functional reset is that Factory Defaults
resets maintenance parameters, such as device and sensor wear, calibration and maintenance
timers. Functional reset does not reset these parameters.
b)
See Data transmission in manual
Foundation Fieldbus for Level Instruments
(7ML19985MP01)
for further details.
4. Click Next, then FINISH to complete the Master Reset.
