Technical information

IM-P343-29 CH Issue 5 59
Display Description
EQUAL
Indicates an equal percentage relationship between the input signal and the
valve travel.
FAST
Indicates a fast opening relationship between the input signal and the valve travel.
T-UP
Facility to slow down the valve opening movement.
T-dWN
Facility to slow down the valve closing movement.
TS1
Setting of % travel for software travel switch 1 (normally open).
TS2
Setting of % travel for software travel switch 2 (normally closed).
%
Indicates percentage of valve travel in automatic operation or
manual control (
MCTL).
mA
Indicates the input signal in mA.
AUTOC
Return to SP200 MENU remaining in automatic control operation.
FILL
Indicates the actuator is being filled with air (manual control before AUTOS).

Indicates that there are no problems with the positioner.
!
An error or warning indication.
ERROR 1
(AUTOS)
Indicates a problem with the mounting position.
ERROR 2
(AUTOS)
Indicates that there is insufficient air pressure to position the valve.
ERROR 3
(AUTOS)
Indicates that the air cannot be vented from the actuator.
ERROR 4
(AUTOS)
Detected stroke too short.
— Software travel switch (TS1 and TS2) - closed.
/ Software travel switch (TS1) - open.
\ Software travel switch (TS2) - open.
STRVL
Indicates the total number of valve strokes (x10).
Value can be retained (RTAIN) or reset (RESET).
RTIME
Indicates the total run time of the SP200 in hours.
Value can be retained (RTAIN) or reset (RESET)
