Technical information

IM-P343-29 CH Issue 558
12.2 Sub-menu display functions
Display Description
VER x.xx Indicates the version of software embedded within the SP200 positioner.
CALIb Provides facility for mounting position adjustment.
RETRN Enables previously stored function values to be recalled.
RTAIN Enables temporary changes made to function values to be retained.
RESET
Enables all function values to be reset to default settings.
Refer to Section 11 for default settings.
MCTL
Provides manual control of the valve.
Use
and keys to fill or vent the actuator.
C-CAL Calibration of the current input.
TRAVL
Selection of percentage of travel display - 0 to 100% or 100 to 0%
depending on valve and actuator configuration.
AUTOS Initiates the autostroke automatic commissioning routine.
AbORT Indicates that the AUTOS commissioning routine has been aborted.
VALVE Selection of 2-port or 3-port valve.
ACT Selection for use with PN5100 or PN6100 series pneumatic actuators.
CTRLA Selection of input signal control action 4 - 20 mA or 20 - 4 mA.
MIN-T Setting of minimum valve travel % to prevent the valve fully closing.
MAX-T Selection of maximum valve travel % to prevent the valve fully opening.
DTRVL
Selection of displaying 0 - 100% travel over the mechanical travel limits or
adjusted MIN-T / MAX-T settings.
MIN-R Selection of the input signal related to the minimum valve travel (MIN-T).
MAX-R Selection of the maximum input signal related to maximum valve travel (MAX-T)
dbANd Selection of % valve position dead-band sensitivity.
S-MIN
Facility to select pre-determined input signal to fully close the valve at
the minimum travel position.
S-MAX
Facility to select a pre-determined input signal to fully close the valve at
the maximum travel position.
Selection of input signal to valve lift characterisation.
Options include:
CHAR
• Linear (LIN)
• Equal percentage (
EQUAL)
• Fast opening (
FAST)
LIN Indicates a linear relationship between the input signal and the valve travel.
