Technical information

IM-P343-29 CH Issue 556
11. Default values and
program settings
Main menu Sub-menu Setting options Default value
Programmed
value
SET
Valve type 2-PORT
(VALVE) 3-PORT
(2-PORT)
SET
Actuator type ON
(ACT) OFF
OFF
SET
Control action Direct (dIRCT)
(CTRLA) Reverse (REV)
(dIRCT)
SET
Minimum travel
(MIN-T)
0 to 66% 0%
SET
Maximum travel 33 to 100% 95% for 2-port
(MAX-T) 100% for 3-port
SET
Displayed % travel ON
(DTRVL) OFF
ON
SET
Minimum input signal
(MIN-R)
4 to 16 mA 4 mA
SET
Maximum input signal
(MAX-R)
8 to 20 mA 20 mA
Dead-band
0.2 to 10% 0.5%
TUNE
(dBAND)
(% of (3% if
input signal span) ACT is 'ON')
TUNE
Minimum shut-off OFF,
(S-MIN) 0 to 20%
0.1%
TUNE
Maximum shut-off OFF, OFF for 2-port
(S-MAX) 0 to 20% 0.1% for 3-port
Characteristic
Linear (LIN),
TUNE
(CHAR)
Equal (EQUAL), (LIN)
Fast (FAST)
Autostroke time
Time-up Autostroke time – (seconds)
TUNE
(T-UP) 180 seconds
4 seconds
if ACT is 'ON'
Autostroke time
Time-down Autostroke time – (seconds)
TUNE
(T-dWN) 180 seconds
4 seconds
if ACT is 'ON'
TUNE
Travel switch 1 OFF,
(TS1) 0 to 100%
(TS1 OFF)
TUNE
Travel switch 2 OFF,
(TS2) 0 to 100%
(TS2 OFF)
RUN Return to menu
Auto (RETRN AUTO)
(RETRN AUTO)
Vent (RETRN VENT)
