9.7 RUN - automatic operation
Fig. 46
AUTO OPERATION
( % TRAVEL)
Return to
SP200 menu
(RETRN AUTO /
RETRN VENT)
Run time
(RTIME)
Return to
SP200 MENU
RUN
mA
(mA input signal)
Stem travel
(STRVL)
Programming notes
Provides the facility to put the valve into automatic operation. Press and
hold key for 3 seconds to start automatic operation. The display will count
down the 3 seconds.
The valve will move to a position in response to the input control signal.
All values stored in the temporary memory will be transferred to the permanent
memory.
Commissioning notes
By pressing and holding the key for 3 seconds all values previously set will be entered
into the permanent memory. The valve will move to a position as dictated by the input
control signal.
To alter or check SET or TUNE values it is necessary to return to SP200 MENU. Press and
hold
key for 3 seconds to return to SP200 MENU. The display will count down the 3 seconds.
There are two options for returning to SP200 MENU:
Option 1 is to stay in automatic control (AUTO) where the valve will continue to position
itself relative to the input control signal.
Option 2 is to vent the actuator (VENT) where the valve will travel to its fail-safe position.
(RETAIN)
(RESET)
(RETAIN)
(RESET)
