Technical information

IM-P343-29 CH Issue 5 25
7.2 3-port valves (with travel setting (TRAVL) 0 - 100%, refer to Figures 27 and 28)
Proceed as above up to Section 7.1.9.
7.2.1 On completion of a successful autostroke press the key once to advance to SET
in main menu.
7.2.2 Press key once to advance to VALVE TYPE.
Press
key to indicate VALVE 3-PORT.
7.2.3 Press key to select VALVE 3-PORT. Continue to press key to return to SET in
main menu.
7.2.4 Press key twice to advance to RUN in main menu. Proceed as described in
Section 7.1.11.
