Datasheet

Product Specification
Shuttle XPC Barebone SG41J1 Black Specification
J-type chassis made of steel
Storage bays: 1x 13.5 cm (5.25") external, 2x 8.9cm (3.5") internal
Dimensions: 32.5 x 21.5 x 19 cm (LWH) = 13.3 liters
Weight: 7.0 kg net, 7.5 kg gross
9.2cm rpm-controlled system fan with 4 pin connector
Kensington Security Slot at the back panel (also called a K-Slot
or Kensington lock) as a part of an anti-theft system
Shuttle FG41, Shuttle form factor
Proprietary mainboard design for Shuttle XPC Barebone SG41J1
Chipset: Intel G41 Express + ICH7 (TDP: 24W + 3.3W)
AMI legacy core
SPI interface, 8MB Flash ROM
Supports PnP, ACPI 3.0
Supports external USB flash memory card boot up
250 Watt mini power supply unit
Input voltage range: 100~240V
Connectors: 20-pin ATX, 4-pin ATX12V
Active PFC (Power Factor Correction)
Socket 775
Supports Intel Core 2 Quad, Core 2 Duo, Pentium Dual Core, Celeron Dual-Core,
Celeron 4xx
Supports 800, 1066 or 1333 MHz front side bus (FSB)
Maximum power consumption: TDP = 95W max.
Processors with 533MHz FSB are not supported.
Please refer the support list for detailed processor support information.
Processor cooling fan is not included
Please purchase an Intel boxed processor.
The maximum cooler dimensions are 7.5 x 7.5 x 8 cm
The mainboard supports temperature-controlled RPM fan speed by the BIOS.
Optional: Shuttle heat-pipe cooling system with 92mm fan
2 x 240 pin DIMM memory slots
Supports Dual Channel with up to 12.8 GB/s data transfer rate
Supports DDR2-800/667 (PC2-6400/5300) unbuffered SDRAM memory
Supports DDR2-1066 (PC2-8500) in overclocking mode *)
Up to a total size of 8 GB, max. 4 GB per DIMM
1 x PCI-Express x16X (v1.1)
1 x PCI (32 Bit)
Supports Dual-slot (double-width) PCI Express x16 graphics cards,
however, you cannot use the PCI slot in this case. ***)
Chassis
Mainboard
BIOS
Power
Supply
Processor
Support
Processor
Cooling
Memory
Support
Expansion
Slots
Page 4 | 2 February 2010
