Datasheet

Product Specification
Supports Socket-775 CPU and up to 8 GB DDR2
You can chose from a wide range of Socket 775 Intel processors
starting from Celeron up to Quad Core with a maximum TDP wattage of
95W. Also the system memory can be installed according your needs
up to a total size of 8GB DDR2-800.
Supports one optical drive and two harddisks
Despite the small housing, the user can install one optical drive and up
to two hard disks into the SG41J1. But what about the heat? Many of
the clever design elements of the XPC get little attention. For example,
the drive rack built into the SG41J1 keeps a space between the hard
disks free for the air flow. Intelligently-engineered airflow mechanics
channels cool air to where it's need most - protecting your investment
and providing optimal performance.
Mini-ITX Mainboard Support
Shuttle expands the capabilities of its chassis, adding support for Mini-
ITX mainboards (17 x 17cm or 6.7 x 6.7 inches). Now, for the first time,
the Shuttle chassis can go beyond the Shuttle mainboard, so you can
easily upgrade or downgrade the mainboard to your desire, without
any modifications to the chassis.
Gigabit LAN Network
Today’s media-rich communications across the Internet and within
organizations are creating new demands on clients in Local Area
Networks. For that reason Shuttle introduces the Gigabit LAN perfor-
mance even in the business and entry level segment of their XPC line.
Solid Capacitors
The new generation of solid capacitors is used in the temperature
sensitive part of the CPU voltage regulator. The lifespan of solid
capacitors is in fact up to six times longer than the more common
electrolytic capacitors.
Serial and parallel ports
The accessory box contains a slot bracket adapter which can be used
to provide one serial and one parallel port at the back panel. The
cable of this adapter will be connected to the onboard LPC port and
one expansion slot (PCI or PCI Express) will be occupied by the
adapter. Many PCs do not have these legacy ports since they have
been superseded for most consumer applications, but they are
commonly still used in applications such as industrial automation
systems, scientific analysis, POS systems and some industrial products.
Page 3 | 2 February 2010
