LEDs and
buttons
Power button
Power LED (white)
Hard disk LED (blue)
Power
supply
External 40W AC/DC power adapter (fanless), 19V / 2.1A
AC Input: 100~240V AC, 50~60Hz
Automatic voltage adjust
Dimensions: 89.5 x 37 x 26.5 mm (LWH)
DC Connector: 5.5/2.5mm (outer/inner diameter)
Optional
accessories
- VESA mount made of metal (PV01)
- Adapter for second 2.5" drive instead of optical drive (PHD2)
24/7
nonstop
operation
This device is approved for 24/7 permanent operation.
Requirements:
- Free circulation of air amongst the PC must be guaranteed.
- Ventilation holes must be clear.
- If a hard disk is installed, this must also be approved for permanent
operation by its manufacturer (max. one hard disk)
Environ-
mental
spec.
Operating temperature range: 0~35°C
Relative humidity range: 10~90% (non-condensing)
Certification
and
Compliance
EMI: CE, FCC, BSMI, C-Tick, CCC
Safety: CB, BSMI, ETL
Other compliances: RoHS, Eup Lot6
This device is classed as a technical information
equipment (ITE) in class B and is intended for use in
living room and office. The CE-mark approves the
conformity by the EU-guidelines:
- EMV-guideline 89/336/EWG electromagnetic tolerance
- LVD-guideline 73/23/EWG use of electric devices
within certain voltage-limits
Comparison: Shuttle Slim-PC Barebone PC XS35/XS36 Series
Model Graphics HDMI DVI D-Sub RS232 WOL Processor Memory (SO-DIMM) Other
XS35 Intel GMA3150 - - Yes - -
XS35GT NVIDIA ION2 Yes - Yes - -
Intel Atom D510
(2x 1.66GHz)
Max. 2GB DDR2-800
1x SO-DIMM slot
Fast
Ethernet
XS35V2 Intel GMA3150 - - Yes - -
XS35GT V2 NVIDIA ION2 Yes - Yes - -
XS35GTA V2
ATI Mobility
Rad. HD 5430
Yes - Yes - -
Intel Atom D525
(2x 1.80GHz)
Max. 4GB DDR3-800
1x SO-DIMM slot
Gigabit
LAN
XS35V3 Intel GMA3650 [2] Yes - Yes - Yes [3]
XS35GTA V3
[1]
ATI Radeon
HD 7410M
Yes - Yes - Yes [3]
XS36V Intel GMA3650 [2] Yes Yes Yes 2x Yes [3]
Intel Atom
D2700
(2x 2.13GHz)
Max. 4GB DDR3-1066
2x SO-DIMM slots
Gigabit
LAN
[1] XS35GTAV3 is also called XS35GS V3 outside EU.
[2] Intel offers sophisticated graphics driver for the integrated Intel GMA3650 graphics only
for Windows 7 32 bit
. Linux can be used in standard graphics mode without video acceleration. (date April 2012)
[3] Supports Wake-on-LAN (WOL), Power fail resume and Resume by RTC Alarm
