Shuttle Barebone XS35GTA V3 Specifications
Fanless and
silent
Passive cooling, no fan noise at all
Perfect to be used in noise-sensitive environments
Fanless, dust-free and thus virtually maintenance-free
Efficiency
Low power consumption:
Power consumption: ca. 19W (idle mode) and ca. 27W (full load)
Chassis
Dimensions without Stand: 25.2 x 16.2 x 3.85 cm (DxHxW)
Weight: 2.1 kg net, 2.8 kg gross
Hole for the Kensington Lock at the back panel
Optional accessory: 75mm and 100mm VESA mounting kit (PV01)
Operation
System
This system comes without operating system.
It is compatible with Windows 7 (32 or 64 bit)
Processor
Intel Dual Core Atom processor D2700 (Codename: Cedarview)
Intel Hyper-Threading technology: 2-threads per core
32 nm manufacturing process, Micro-FCBGA11 package
Intel 64 architecture, Core clock: 2.13 GHz
L2 Cache: 1024kB , TDP: max. 10W
Supports SSE2, SSE3, SSSE3, Execute Disable Bit
Integrated North Bridge with controller for memory and graphics
Cooling
Passive, completely fanless cooling through convective heat transfer
Warning: Please make sure the system is always placed
upright using either its stand or the optional VESA mount.
Ventilation holes must not be blocked to ensure sufficient cooling.
Chipset
Intel® NM10 Express Chipset (south bridge)
Platform Controller Hub (PCH)
Code name: Tiger Point
BIOS
AMI BIOS in a 8Mbit Flash ROM supports PnP, ACPI 2.0
Supports external USB flash memory card boot up
Supports Power fail resume / AC power on state / always on / always off
Supports Wake-on-LAN (WOL) from S3, S3, S5 ACPI states
Supports Unified Extensible Firmware Interface (UEFI)
Memory
2x SO-DIMM slots with 204 pins
Supports two modules DDR3-1066 (PC3-8500)
DDR3-1333 is supported at DDR3-1066 clock rate
Supported maximum capacity: 4 GB
Optical
drive (opt.)
Support an optical DVD or Blu-ray slim-line drive
Serial ATA interface, 12.7mm height, Slimline SATA connector
