Remarkable graphics power and

entirely fanless

Just 3.6 cm thin, with dual-core processor and AMD Radeon™ HD

7410M graphics card – but completely fanless. Ideal for when low-

noise operation is essential – enjoy full-HD movies and 3D content with

a minimum of background noise. The XS35GTA V3 features two monitor

outputs (one of which is an HDMI interface) to connect two screens

simultaneously. Despite its compact size, there is still space for two

drives in the case.

Feature Highlights

Chassis

 Slim 1.5 litre chassis

 Dimensions: 25.2 x 16.2 x 3.85 cm

 Hole for the Kensington Lock

 Optional: VESA75/100 mounting kit PV01

Operating

system

 Without operating system

 Compatible with Windows 7 (32/64 bit)

CPU

 Intel Atom D2700 Dual Core (2.13GHz)

Chipset

 Intel NM10 Express Chipset

Graphics

 AMD Radeon HD 7410M, 512MB DDR3

 DirectX 11, Shader Model 5.0

Memory

 2x SO-DIMM socket (204 pins)

 Supports max. 4GB DDR3-1066

Supports DDR3-1333/1600 at 1066MHz

Storage

 Supports one optical slimline drive

 Supports one 2.5” SATA hard disk or SSD

 With 4-in-1 card reader

Connectors

and

WLAN

 HDMI v1.3

 D-Sub VGA

 5x USB 2.0 (1x front, 4x rear)

 2x Audio (mic, head phone)

 Gigabit-LAN

 WLAN 802.11 b/g/n

Power supply

 External 40W fanless power supply

Applications

 Basic and Home-Media

Fanless

Images are only for illustration purposes.

The optical drive is not included.

Shuttle order no: PEB-XS35A301

arebone

XS35GTA V3

Slim PC

Summary of content (10 pages)

PAGE 1
Product Specification Barebone Remarkable graphics power and entirely fanless Just 3.6 cm thin, with dual-core processor and AMD Radeon™ HD 7410M graphics card – but completely fanless. Ideal for when lownoise operation is essential – enjoy full-HD movies and 3D content with a minimum of background noise. The XS35GTA V3 features two monitor outputs (one of which is an HDMI interface) to connect two screens simultaneously. Despite its compact size, there is still space for two drives in the case.
PAGE 2
Product Specification Shuttle Barebone XS35GTA V3 - Product Features Slim and stylish Designed as a space-saver, this sleek 1.5 litre nettop PC only measures 3.8cm in width. It maximizes space whether it is placed upright using its stylish stand or affixed to the back of a display with the optional VESA mounting kit (PV01).
PAGE 3
Product Specification Highly energy-saving The XS35GTA V3 barely consumes, depending on system load, about 19~27 Watts. Running the device*) 5 days a week for eight hours a day, the annual consumption would amount to approx. 60kWh which would mean just 12 Euros on the power bill (20 Euro ct/kWh) - way less than a conventional desktop PC draws.
PAGE 4
Product Specification Kensington Lock This is a small, metal-reinforced hole as part of an anti-theft system. As known from notebooks, this Mini-PC can also be safely locked by tieing it to a solid object. (The lock-and-cable apparatus is not included.) Optional second hard disk (Accessory PHD2) The optional accessory PHD2 supports a second 2.5" hard disk. Please note, that the bay for the optical drive will be occupied then.
PAGE 5
Product Specification 24/7 nonstop operation Shuttle XS35GTA V3 is officially approved for 24/7 permanent operation. Thanks to its low power consumption and completely passively cooling, this PC runs highly reliable making it perfectly suitable for digital signage and POI/POS applications.
PAGE 6
Product Specification Shuttle Barebone XS35GTA V3 Specifications Passive cooling, no fan noise at all Perfect to be used in noise-sensitive environments Fanless, dust-free and thus virtually maintenance-free Efficiency Low power consumption: Power consumption: ca. 19W (idle mode) and ca. 27W (full load) Chassis Dimensions without Stand: 25.2 x 16.2 x 3.85 cm (DxHxW) Weight: 2.1 kg net, 2.
PAGE 7
Product Specification ATI Graphics Card Integrated Audio AMD Radeon™ HD 7410M graphics processor (Codename "Seymore-LP") Dedicated 3D graphics card VRAM: 512MB DDR3, 800MHz, 64 bit (no shared memory) 160 Stream Processing Units, 40nm technology Supports DirectX 11, Shader Model 5.0, OpenGL 4.1 Unified Video Decoder (UVD 3) dedicated video playback accelerator Supports full HD decode (1080i/p) Support for up to 2 simultaneous displays: 1) Digital HDMI™ 1.4a, max.
PAGE 8
Product Specification LEDs and buttons Power button Power LED (white) Hard disk LED (blue) External 40W AC/DC power adapter (fanless), 19V / 2.1A AC Input: 100~240V AC, 50~60Hz Automatic voltage adjust Dimensions: 89.5 x 37 x 26.5 mm (LWH) DC Connector: 5.5/2.5mm (outer/inner diameter) Optional accessories 24/7 nonstop operation Environmental spec. Certification and Compliance - VESA mount made of metal (PV01) - Adapter for second 2.
PAGE 9
Product Specification Shuttle Barebone XS35GTA V3 – Connectors 1 2 3 4 5 6 7 Power button Power LED Hard disk LED 4-in-1 card reader USB connector Bay for the optical slimline drive *) Vertical stand Back Panel A B C D E F G H I Microphone input Head phone output (Line out) Gigabit LAN connector (RJ45) 4x USB connectors D-Sub/VGA connector HDMI connector Hole for the Kensington-Lock Connector for the power adapter Vertical stand *) Note: The optical drive is not included.
PAGE 10
©2012 by Shuttle Computer Handels GmbH (Germany). All information subject to change without notice. Pictures for illustration purposes only. Product Specification Images are only for illustration purposes. The optical drive is not included. Page 10 | 13 June 2012 www.shuttle.com Shu t tl e Computer Han dels GmbH Fritz- Strassmann-S t r. 5 25337 Elmshorn | Germany Tel. +49 (0) 4121-47 68 60 Fax +49 (0) 4121-47 69 00 sales@shuttle.
