User's Manual

8
Parts and Accessories
Troubleshooting
No power: Check battery and power supply connections and voltage.
Check the power switch on the transmitter.
The LCD displays "E0 00" or similar code: Exit master list mode by
holding the SET button for ten seconds.
Can't turn off or change settings on the transmitter or receiver: The
interface is locked. See the section on locking the interface.
No audio: If the antenna and battery indicators do not appear on the re-
ceiver, then it is not receiving a signal from the transmitter. Make sure the
transmitter and receiver are tuned to the same group and channel.
Faint or distorted audio: Adjust transmitter gain, bodypack attenuator
switch, and receiver output level.
Noise: Noise usually results from wireless interference or a weak signal
from the transmitter. See Tips for Improving System Performance.
Tips for Improving System Performance
If you encounter wireless interference or dropouts, try the following:
• Replace the transmitter battery with a fresh alkaline battery (avoid
rechargeable batteries).
• Choose a different frequency channel.
• Reposition the antennas so there is nothing obstructing a line of sight to
the transmitter (including the audience).
• Avoid placing transmitter and receiver where metal or other dense
materials may be present.
• Move the receiver to the top of the equipment rack (or remote mount
antennas outside the rack).
• Remove nearby sources of wireless interference, such as cell
phones, two-way radios, computers, media players, and digital signal
processors.
• Keep transmitters more then two meters (6 feet) apart.
• Keep the transmitter and receiver more than 5 meters (15 ft) apart.
• Point the receiver antenna tips away from each other at a 45° angle,
and keep them away from large metal objects.
• During sound check, mark "trouble spots" and ask presenters or
performers to avoid those areas.
Replacement Parts
AC Adapter (120 VAC, 60 Hz) PS41
AC Adapter (220 VAC, 50 Hz) PS41AR
AC Adapter (230 VAC, 50/60 Hz) PS41AZ
AC Adapter (230 VAC, 50/60 Hz, Europlug) PS41E
AC Adapter (230 VAC, 50/60 Hz) PS41UK
AC Adapter (100 VAC, 50/60 Hz) PS41J
SM58
®
Cartridge with Grille (ULX2/58) RPW112
BETA 58A
®
Cartridge with Grille (ULX2/ BETA 58) RPW118
SM86 Cartridge with Grille (ULX2/SM86) RPW114
SM87A Cartridge with Grille (ULX2/87) RPW116
BETA 87A Cartridge with Grille (ULX2/BETA 87A) RPW120
BETA 87C Cartridge with Grille (ULX2/BETA 87C ) RPW122
Matte Silver Grille for SM58 RK143G
Matte Silver Grille for SM86 RPM226
Matte Silver Grille for BETA 58A RK265G
Matte Silver Grille for BETA 87A RK312
Black Grille for SM87A RK214G
Black Grille for BETA 58A RPM323G
Black Grille for BETA 87A and BETA 87C RPM324G
Belt Clip 44A8013A
1/4-Wave Antenna (470 - 752 MHz) UA400B
1/4-Wave Antenna (774 - 952 MHz) UA400
1/2-Wave Antenna (774 - 865 MHz) UA8-774-865
1/2-Wave Antenna (638 - 698 MHz) UA8-638-698
1/2-Wave Antenna (554 - 590 MHz) UA8-554-590
1/2-Wave Antenna (740 - 814 MHz) UA8-740-814
1/2-Wave Antenna (470 - 530 MHz) UA8-470-530
1/2-Wave Antenna (746 - 784 MHz) UA8-746-784
1/2-Wave Antenna (572 - 596 MHz) UA8-572-596
1/2-Wave Antenna (578 - 638 MHz) UA8-578-638
Included Accessories
Microphone Stand Adapter (ULX2) WA371
Grip/Switch Cover (ULX2) WA555
Zipper Bag (ULX1) 95A2313
Zipper Bag (ULX2) 95B2313
Screwdriver (ULX2) 80A498
Optional Accessories
Passive Antenna Splitter/Combiner Kit UA221
UHF Line Amplifier UA830WB
UHF Powered Directional Antenna UA874US
UA874E
UA874WB
UA874X
UHF Antenna Power Distribution Amplifier (U.S.A.) UA844SWB
UHF Antenna Power Distribution Amplifier (Europe) UA844SWB-E
UHF Antenna Power Distribution Amplifier (UK) UA844SWB-UK
33 m (100 ft.) BNC–BNC cable UA8100
1.8 m (6 ft.) BNC–BNC cable UA806
Antenna Rack Panel UA440
Front Mount Antenna Kit (Includes 2 cables and 2 bulkhead adapters) UA600
Remote Antenna Bracket with BNC Bulkhead Adapter UA505
Rack Mount Kit for single Receiver UA506
Rack Mount Kit for Two Receivers UA507
Carrying Case WA610
Microphone Adapter Cable (XLR) WA310
