Connect curtain to controller and PC

- CurtainandcontrolleraretransportedinblueShowLEDflightcases.

- Thecontrollerislikewisebuiltinaspecialdesignedstoragecase.Whenremovingfrontandback
lidofthecontrollerflightcase,youwillnoticethatthereisatrussclampforeasyattachmentof
controllertotrussortube.Alternatively,thecontrollercanbeplacedontheground.

- It’salsopossiblethatthecontrollersareinstalledina19’touringrack.Pleaseremovefrontand
backlidofthetouringrack.

- Includedintheflightcaseareextensioncables,thelengthofthesecablesdependsonthe
surfaceofthecurtain.Thesecablescan beusedifthere’sabigdistancebetweenthecables
comingoutofthecurtainandthecontroller.Simplyconnectextensioncablestocablescoming
outofthecurtain.

- Connectplugstocontroller.
Theplugsarenothotswappable,alwaysmakesurethecontrolleristurnedoffwhenyouinsert
theplugs.


PleasenotethatfornowonlytheeightpluginputsandtheEthernetinputarefunctional.The
DMXin/outputdoesn’toperateyet.

- Connectpowercordofcontrollertopowersupply.

- LinkcontrollerviaEthernetcabletoPC.

- SwitchcontrollerON.Thecontrollerwilldetecttheinsertedplugs.Ifyou’veattached8plugsthe
displayshouldread“READSUCCES”8times.Thendisplayshouldread8PLUGSDETECTED.

- ContinuewithManualShowLEDDESIGNER


7

our te
Should you encounter any problems operating the ShowLED Animation curtain please
contact Amelia NV. at [phone].
Never try to open up/repair the Animation curtain without consulting
chnicians.
