Specifications

Chapter 1: Installing the software
Safety instructions
WARNING
Toavoidelectricshockthepowercordprotectivegroundingmustbeconnectedtoground.
Makesureyouunderstandthefunction ofeachconnectionbeforeyouconnectit.Seethatall
connectionsaremadecorrectlybeforeturningonthecontroller.
Alwaysdisconnectthecontrollerfromthemainssupplywhenconnectingthesignalleads,thepower
cordshouldbeconnectedlast.
Donotapplyvoltagehigherthan250Vactothecontroller.(Seealsotechnicaldata)
ThecontrollerhasafuseaccessibleontheIECpowerinlet;replacethemonly withthecorrecttype.See
belowhowtoreplacethem.
Toinsuregoodventilationinordertopreventfirecausedbyoverheating,donotinstallorusethe
controllerinaclosedspace.Makesurethattheventilationexitsatthesideandthebackofthe
controllerarenotblocked.
Takecarewiththeenvironmentallimits.Donotexceedthem.(Seetechnicaldata)
Keepaminimumdistanceof1meterbetweenyou(ortheaudience)andtheLEDs.
DonotstareintotheLEDs,especiallywhennarrowangleLEDsareused.
ThiscontrollerisdesignedandtestedfordrivingLEDs;donotuseitforotherpurposes.
Donotexposethecontrollertowater(rain)ordirectsunlight.
Donotsubjecttoexcessiveshockbydroppingtheunit.
Howtoreplacethefuses

Disconnectthepowercord!Pulloutthefusedrawerbelowthemainsinputandreplacethefuseatthe
backofthefusedrawerwiththesparefuseatthefrontofthefusedrawer.Ifthereisnosparefuseuse
therightkindoffuses.(Fuse,slowblow6.3A,20x5mm).Connectthepowercordandcheckifthe
controllerisworkingproperly.

3


ShouldyouencounteranyproblemsoperatingtheShowLEDAnimationcurtain
pleasecontactAmeliaNV.at+3232703636.
Never try to open up/repair the Animation curtain without consulting
our technicians.
