User's Manual

ManualsBrandsShenzhen Yifang Digital Technology ManualsElectronicsMobile Digital Pen

Accessories

z Receiver ● USB Cable(Mini + Micro) ● Digital Pen（XN510）

z Ink Refill ● Refill Extractor ● User Manual

Overview of Receiver

A. Clip- Holds paper of Size A4 (default).

B. Reset hole- Reset the device.

C. Power button- Press to turn on/off the device.

D. Micro USB port- Connects to Micro USB cable for charging.

E. LED indicator- Indicate the various working status of the device.

Note: For the sake of power saving, usually only one LED indicator will light to

indicate related statuses at one time:

Power on: two LEDs blink once;

Charging: red LED blinks briefly;

Fully charged: red LED lights for a while

；

Low battery: red LED blinks slowly

；

Standby: green LED blink slowly

；

Writing: green LED blink briefly

；

Summary of content (7 pages)

PAGE 1
Accessories z Receiver z Ink Refill ● USB Cable(Mini + Micro) ● Refill Extractor ● Digital Pen（XN510） ● User Manual Overview of Receiver A. B. C. D. E. Clip- Holds paper of Size A4 (default). Reset hole- Reset the device. Power button- Press to turn on/off the device. Micro USB port- Connects to Micro USB cable for charging. LED indicator- Indicate the various working status of the device.
PAGE 2
Digita al Pen Mini USB port F．M Co onnects to PC via a Mini USB ca able for charging.. Note：Disconnect the e USB cable whe en the device hass charged for abo out 2 hours. Charging indica ator: Lights red d when chargin ng is going on and goes out G．C when n charging comp pletes; blinks oncce the battery is low. Note：Please use the e dedicated USB cable provided to ogether with this pen to connect the Receiver R and the e pen. How w to Use e the Dig gital Pen W WARNING: Do no ot attempt to ope en the pen.
PAGE 3
二、 Software Application A 1.Sysstem requirementts： y y iPhone 4s /iP Pad3 or above（w with iOS7.0 or ab bove）； Android 4.3 or o above, with BL LE4.0； 2. Run the application n “CloudMemo+”：： a) User can downlo oad the applicatiion “CloudMemo o+” to your mobile devices from A AppStore, Google Play, Android Market or by sccanning the two-d dimention code and install it; b) Find the “CloudMemo+” icon on n the app menu screen of the Android A or iOS device before tap pping to open it.
PAGE 4
d) Tap on the device name that is identical with that on the bar code of the receiver from the found device list, and then enter note-taking mode. At the bottom of the screen, there will appear some words “device connected successfully, ready to take notes”. You can take note now. e) Fix the receiver on the top-center a piece of paper in size A4. Hold the pen and write as usual. Whatever you write or draw with the pen will be displayed on the screen of your mobile device. Note: 1.
PAGE 5
g) Tap on “Note” icon on the top right corner to check your recent notes. 三、 Description of the interfaces Notes Management Upload Management：Modify the name of device or get back to device list. Note：Check all notes that have been saved or uploaded. Share: Upload your notes to social networks.
PAGE 6
Remarks: To share your notes, please make sure your mobile device is connected to the Internet. Pen: Select the options of pen width. Wallpaper: Change the wallpaper (background) of your notes. Eraser: Erase paticular part of your writing or drawing, or clear the whole page. Color: Change the color of your ink. Photo: Take photos or load an existing picture for editing or to set as wallpaper. Save：Save your current note.
PAGE 7
FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
