Portable ECG MONITOR

Model： PB-20

Content

1. The Basics

...........................................................................................................................................................................................

1.1 Safety

..................................................................................................................................................................................................

1. Introduction

........................................................................................................................................................................................

1.1 Intended Use

......................................................................................................................................................................................

1.2 Contraindications

...............................................................................................................................................................................

1.3 About Portable ECG monitor

............................................................................................................................................................

1.4 Main Screen

.......................................................................................................................................................................................

1.5 Result Screen

......................................................................................................................................................................................

1.6 Symbols

..............................................................................................................................................................................................

2. Getting Started

...................................................................................................................................................................................

2.1 Unpacking

..........................................................................................................................................................................................

2.2 Power On/Off

.....................................................................................................................................................................................

2.3 Initial Settings

.....................................................................................................................................................................................

3. Using the device

................................................................................................................................................................................

3.1 Prior to Use

........................................................................................................................................................................................

Before using ECG

........................................................................................................................................................................................

3.2 ECG Recorder

.....................................................................................................................................................................................

About ECG Recorder

..................................................................................................................................................................................

Measuring with Cable

.................................................................................................................................................................................

4. Settings

...............................................................................................................................................................................................

4.1 Opening Settings Menu

....................................................................................................................................................................

4.2 Turning On/Off Bluetooth

..............................................................................................................................................................

4.3 Setting ECG Length

.........................................................................................................................................................................

4.4 Changing User Mode

......................................................................................................................................................................

4.5 Changing Brightness

.......................................................................................................................................................................

4.6 Turn on/off voice

.............................................................................................................................................................................

4.7 Setting Date & Time

........................................................................................................................................................................

4.8 Erase Data

........................................................................................................................................................................................

4.9 Factory Reset

....................................................................................................................................................................................

4.10 Identify Software Version

................................................................................................................................................................

5. Review ECG Recorder

......................................................................................................................................................................

6. Maintenance

....................................................................................................................................................................................

6.1 Warranty

...........................................................................................................................................................................................

6.2 Battery

..............................................................................................................................................................................................

6.3 Cleaning

..............................................................................................................................................................................................

6.4 Trouble Shooting

...............................................................................................................................................................................

7. Accessories

.........................................................................................................................................................................................

8. Specifications

.....................................................................................................................................................................................

9. FCC Statement

...................................................................................................................................................................................

10. Electromagnetic Compatibility

.........................................................................................................................................................

User’s Manual

Summary of content (19 pages)

PAGE 1
User’s Manual Portable ECG MONITOR Model： PB-20 Content 1. The Basics........................................................................................................................................................................................... 2 1.1 Safety.................................................................................................................................................................................................. 2 1. Introduction.............................
PAGE 2
1. The Basics Caution: Federal law restricts this device to sale by or on the order of a physician. This manual contains the instructions necessary to operate the product safely and in accordance with its function and intended use. Observance of this manual is a prerequisite for proper product performance and correct operation and ensures patient and operator safety. This manual is based on the maximum configuration of Portable ECG monitor. 1.
PAGE 3
immediately if you experience symptoms that could indicate acute disease.                      Do not self-diagnose or self-medicate on the basis of this device without consulting your doctor. In particular, do not start taking any new medication or change the type and/or dosage of any existing medication without prior approval.
PAGE 4
The device is intended to give some suggested symptoms such as regular heart beat, irregular heart beat, low HR and high HR. 1.2 Contraindications The product is not intended for use in patients with cardiac pacemakers or other implantable devices. 1.3 About Portable ECG monitor product name: Portable ECG monitor Product model: PB-20 1. Touch Screen Use the pad of your finger to tap or swipe on the touch screen. Do not use your fingernail or any other object to tap the screen. 2.
PAGE 5
ECG cable with 2 lead wires Connect the micro D connector side to the device and the other side to your left/right wrists or right clavicle /left lower abdomen. 1.4 Main Screen The Main Screen is shown as below. User Mode: Single 9. User Mode: Dual Tapping a button in the Main Screen will start a measurement, activate a function, or open corresponding menu. 1.5 Result Screen This device provides ECG Recorder For each measurement, a Result report will be provided after the measurement is finished.
PAGE 6
 Select button to start a measurement again.  Select button to review waveform.  Press button to open the help information. In the Result Screen, if there is no operation for 1 minutes, the device will automatically return to upper menu until it powers off. 1.6 Symbols Symbol Meaning Application part type BF Manufacturer Symbol for “ENVIRONMENT PROTECTION – Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
PAGE 7
regulations and keep it out of children’s reach. The equipment might be contaminated during storage and transport. Before use, please verify whether the packages are intact. In case of any damage, do not apply it to patients.  2.2 Power On/Off Press the Power On/Off button to power on the device. Press and hold Power On/Off button for 2 seconds to power off the device. 2.3 Initial Settings The first time Portable ECG monitor is powered on, you can follow the steps below to set up your monitor.
PAGE 8
ECG electrodes are attached to the patient, to prevent them from contacting conductive parts or earth.      If using the ECG for long-term monitoring, periodically inspect the electrode application site to ensure skin quality. If the skin quality changes, replace the electrodes or change the application site. Do not use this device during defibrillation. Interference from a non-grounded instrument near the patient and electro surgery interference can causes problems with the waveform.
PAGE 9
amplitude is too small for better interpret. Measuring with Cable To start an ECG Recorder measurement without cable, 1. In the HeartCheck model, tap the icon. 2. Choose the named method A or named method B. 3. Follow the instructions to connect the ECG cable and place the ECG electrodes.
PAGE 10
In the Settings menu, you can  Tap and button to page up or down  Tap home button to close the Settings menu 4.2 Turning On/Off Bluetooth Portable ECG monitor has built-in Bluetooth wireless connectivity, which enables exporting measured records from the device to mobile devices use Bluetooth protocol. To turn on the Bluetooth: 1. Switch on the device Bluetooth in Setting->Bluetooth. 2. Make sure the phone Bluetooth is enabled. 3.
PAGE 11
4.6 Turn on/off voice In the Settings menu, tap the to turn off voice directly. “ ” means the voice is turned on. 4.7 1. 2. 3. Setting Date & Time In the Settings menu, tap . Tap “+” or “-” button to change the date, then tap Tap “+” or “-” button to change the time. 4. Tap . to finish the setting. 4.8 Erase Data 1. In the Settings menu, tap the 2. Tap to erase all data, tap to cancel option. 4.9 Factory Reset 1.
PAGE 12
 Select to change the waveform amplitude.  Press Home button to return Daily Check list. After the ECG waveform is replayed, it will automatically return to the previous interface.  Select to return to the previous interface.
PAGE 13
  When choosing a third-party USB charging device, select one that complies with IEC 60950. The service life of the battery will depend on the conditions of use, but on average it will support 500 charging / discharging cycles. 6.3 Cleaning    Warnings Have the device repaired by authorized service centers only, otherwise its warranty is invalid. Clean the device per week, carefully swabbing the device surface with a soft cloth or cotton swab with rubbing 70% alcohol.
PAGE 14
8. Specifications Classifications Degree protection against electrical shock Protection against electric shock Type BF Electro-magnetic Compatibility Group I, Class B Apply part Environmental Item Temperature Relative humidity (noncondensing) ECG electrode Operating 5 to 45°C 10% to 95% Storage -25 to 70°C 10% to 95% Barometric 700 to 1060 hPa 700 to 1060 hPa Degree of dust & water resistance Drop test Physical Size Packing size Weight Display Wireless connectivity IP22 1.
PAGE 15
9. FCC Statement FCC ID: 2ADXK-6623 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Note: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance.
PAGE 16
RF emissions CISPR 11 Class B Harmonic emissions IEC 61000-3-2 Class A Voltage fluctuations/ flicker emissions IEC 61000-3-3 Complies The model Portable ECG monitor is suitable for use in all establishments, including domestic establishments and those directly connected to the public low-voltage power supply network that supplies buildings used for domestic purposes.
PAGE 17
810 870 2 0.3 28 28 930 1720 1845 1970 2450 2 0.3 28 28 2 0.3 28 28 0.2 0.3 9 9 5240 5500 5785 frequency of the transmitter. Recommended separation distance Where P is the maximum output power rating of the ransmitter in watts (W) according to the transmitter manufacturer and d is the recommended separation distance in meters (m). Field strengths from fixed RF transmitter, as determined by an electromagnetic site survey, should be less than the compliance level in each frequency range.
PAGE 18
a The ISM (industrial, scientific and medical) bands between 0,15 MHz and 80 MHz are 6,765 MHz to 6,795 MHz; 13,553 MHz to 13,567 MHz; 26,957 MHz to 27,283 MHz; and 40,66 MHz to 40,70 MHz. The amateur radio bands between 0,15 MHz and 80 MHz are 1,8 MHz to 2,0 MHz, 3,5 MHz to 4,0 MHz, 5,3 MHz to 5,4 MHz, 7 MHz to 7,3 MHz, 10,1 MHz to 10,15 MHz, 14 MHz to 14,2 MHz, 18,07 MHz to 18,17 MHz, 21,0 MHz to 21,4 MHz, 24,89 MHz to 24,99 MHz, 28,0 MHz to 29,7 MHz and 50,0 MHz to 54,0 MHz.
PAGE 19
information. Disclosure of the information in this manual in any manner whatsoever without the written permission of Viatom is strictly forbidden. Contents of this manual are subject to changes without prior notice. All information contained in this manual is believed to be correct. Viatom shall not be liable for errors contained herein nor for incidental or consequential damages in connection with the furnishing, performance, or use of this manual. Shenzhen Viatom Technology Co., Ltd.
