User's Guide

17
Install a SIM/SD Card
Insert a Nano SIM/microSD card
1. From the back of the phone, insert a ngernail into the small slot at the
bottom left corner and gently pull up to remove the back cover.
Note: The back cover cannot be removed while the charger is plugged in.
2. On the back of the phone, slide the Nano SIM card into the SIM card slot at
the top left of the phone with the gold contacts facing down.
3. Slide the microSD card into the SD card slot at the top left of the phone.
4. Replace the back cover and press gently until it snaps into place.
microSD NanoSIM
Back removal notch
Mount an SD card
1. With an SD card inserted, swipe up from the Home screen to access Apps
and tap Settings .
2. Tap Storage > SD CARD.
3. Tap MOUNT on the prompted screen.
