BuildingForce-XD Cell Phone Signal Booster Manual Operational Diagram (How It Works) Package Contents Page 2 Basic Signal Level Knowledge Page 3 Preparation Page 4 Installation Step By Step Page 5 - 12 Trouble Shooting Page 13 - 14 Manufactured and Warranted by SolidRF Inc. www.solidRFinc.
Working Diagram (How It Works) 1 2 3 1. 2. 3. 4. The outdoor antenna catches the signal from the tower. Sends signal to the booster through a coax cable. The booster amplifies the signal then rebroadcasts the signal indoors to all mobile devices within range. The system also works in reverse; amplifying outgoing signal back to the tower. The size and the coverage area and the strength of the boosted signal are directly related to two key factors: 1. Signal strength received by the outdoor unit.
Signal transmission loss and power level Coverage area ability Note: FCC regulations limit the amplification of all cell phone boosters in order to prevent damage to the telecommunications infrastructure. Therefore, the maximum coverage area of a booster depends on the original power level of the signal captured by the outdoor unit. Notice: Not recommended when outdoor signal strength is less than -110dbm(3G/1x) or -120dBm(4G/LTE).
Preparation Find a cell tower nearby! There are a variety of resources available online, here are some third party websites and app recommended. Use these to locate your nearest cell tower, either by street address of GPS coordinates. For U.S. websites: www.antennasearch.com/ www.cellmapper.net/ www.cellreception.com/towers For Canada website: www.cellmapper.
Test Installation We STRONGLY recommend doing a test installation before finalizing the installation. Doing a test installation of your cell phone booster ensures that you will get the optimal performance from your system.
Step3: Select the Location for the Outside Unit 1. This is the most critical step and will determine the overall performance of the booster system. 2. Using the same method described in Step 1, walk around the outside of your home and test the signal strength. Determine where you have the strongest signal (the dBm reading is closest to zero). 3. Generally, the strongest signal will be located on the side of your home facing the nearest cell tower.
Step 4: Temporarily Mount the Outside Antenna Use one of the tow options to mount the outside antenna on your roof on the side of the house with the strongest signal A B Caution In order to achieve the best signal coverage effect, there is a certain distance requirement between the indoor and outdoor units. Make sure the inside and outside units are facing away from each other.
2.Connect the outside antenna to the “OUTSIDE” port of booster. 3.Connect the 45 ft RG11 cable to the booster at the “INSIDE” port. 4.Connect the other end of the coax cable to splitter at the “INPUT” port, and two inside antennas' cables connect to the other side port. 5.Connect the other end of the coax cables to the panel antennas. 6.Plug in the power adaptor and connect it to the nearest power outlet (surge protector recommended).
Step6: Evaluate the Effects • • Now that the booster is up-and-running, re-test the signal strength inside your home at the same locations from Step 1. If the number is higher (dBm reading is closer to zero) than the original reading, your booster is working. If your signal is not stronger, check the LED lights on the booster and refer to the “Quick Troubleshooting” section at the end of the manual. Test No Record Location Record(dBm) 1 2 3 4 5 Decibel Gain vs.
Step7: Finalizing Outdoor Antenna Installation Once you have tested the performance of the signal booster and made all necessary adjustments, it’s time to finalize the installation. Outdoor Antenna Installation Make sure that the outside antenna is mounted at least 3 feet away from any windows. Option A : Outside Roof Pole Mount (Best Choice) Use an existing pole to mount the outdoor unit in the optimal signal location. Use the picture for reference.
Step9: Finalizing Booster Installation Mount the booster: Keep away from heat and don't cover booster Booster will about 30 degrees Fahrenheit higher than the ambient temperature, which is a normal phenomenon. Step10: Finalizing and Securing Cable Route • • • • Find the best route for the cable. Follow the lines of your home to hide the cable in eaves or between the soffit and the exterior wall. If needed, cable clips can be purchased at most hardware stores.
Caution Seal and Fix the Connector Secure the cable near the antenna to prevent cable damage caused by wind shaking Properly Handle Excess Cables If the coiled cable is too close to the antenna or booster, the system will be unstable. Make sure these coiled cables are more than 6 feet(2 meters) from the antenna or booster Make sure these excess coiled cables are more than 6 feet(2 meters) from the antenna or booster can make your system work more stable.
Quick Trouble shooting Correct functioning: • Power Light should be solid green solid green will be illuminated after the power is turned on. Power Light Incorrect Functioning: (Please see the Troubleshooting Guide for further details) Trouble Shooting: No Signal Improvement Step 1. If the LED is off please check power. Ensure the DC power is plugged in and the LED Power Light is lighting.
Trouble Shooting: No Signal Improvement Step 2. If the LED is solid “RED”, please check cable connections. Ensure the feeder, Booster and outdoor antenna are securely connected to the coax cable. Solid Red after the power is turned on. Step 3. Double check the location of outdoor and indoor units. Make sure that the Minimum Separation Requirements have been met. Make sure that the outside antenna is not pointed towards the inside antenna.
Technical Specification LTE LTE Cellular PCS (band 12) (band 13) ( band5) (band 25/2) AWS (band 4) Uplink 698-716 776-787 824-849 1850-1915 1710-1755 Downlink 728-746 746-757 869-894 1930-1995 2110-2155 Uplink 65 65 65 68 68 Downlink 68 68 68 70 70 Frequency (MHz) Gain Output power 26dBm(Uplink)/10dBm(Downlink) Noise figure <5dB In-band Flatness <9dB Weight 2.65Kg EIRP 1W Impedance 50 ohm Operating temperature -5°~60° Current ≦1.
Safety Guidelines To uphold network protection standards and ensure compliance, all active cellular devices must maintain a separation distance of at least six feet between the inside unit antenna and outside unit antenna and at least four feet of separation distance from the inside unit. Use only the power supply provided in this package. Use of a non-SolidRF product or accessory may result in damage to the equipment or components of the equipment.
FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment . This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20cm between the radiator &you body. Any Changes expressly or modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment.
Safety Guidelines To uphold network protection standards and ensure compliance, all active cellular devices must maintain a separation distance of at least six feet between the inside unit antenna and outside unit antenna and at least four feet of separation distance from the inside unit. Use only the power supply provided in this package. Use of a non‐SolidRF product or accessory may result in damage to the equipment or temperature‐controlled components of the equipment.
