3.Coolingfan:Themomentwhenthepoweristurnedon,thecoolingfanrotates
forabout2seconds;Whenthebasestationisinoperationandthetemperature
isover45℃, thefanstartstorotatefordissipation.
4. Battery port: 12V power supply or battery power supply. When the po
wer
supplymodule(220V) isinnormaloperation,theportisincharging/idlestate,
functioningasastandbypowersupply;Incaseofpowermodulefailure/power
cut‐off, thestandbypowerisused. Whenconnectingthestandbypower,take
caretothepolarityofpowersupply.
5. Amplifier output port: the amplifier po
wer output port of base station.
Maximumpoweroutput:50~60W.
6. IP port: used for IP networking. It applies the international standard line
sequence.
7.TX&RXmoduleport:inputportofreceivingsignals.
8.Highendoftheduplexer:input/outputportofhighfrequencysignals
9.ANTport:an
tennainterface
10.Lowendoftheduplexer:input/outputportoflowfrequencysignals

Note: Locations of the above ports are subject to changes. If there is any
inconsistency of port sequence in the actual product you receive, the actual product
will govern.
