User's Manual

 Owner’sManual
25

Co‐channelRejection 12dB
Blocking 84dB
Inter‐modulation 70dB
SpuriousResponseRejection 70dB
ConductedSpuriousEmission ‐57dBm

Transmitter
FrequencyStability ±0.1ppm
RFOutputPower 50W/5W
MaximumOutputPowerTole rance 
±1.5dB（Normal）/+2/‐3dB（Extreme）
AdjacentChannelPower ‐65dB@12.5KHz/‐75dB@25KHz
Conducted/RadiatedInterference
（Antenna,transmitmode）
9kHz~1GHz≤‐36dBm
1GHz~12.75GHz≤‐30dBm
Conducted/RadiatedInterference
（Antenna,standbymode）
30MHz~1GHz≤‐36dBm
1GHz~12.75GHz≤‐30dBm
Inter‐modulationattenuation
≤‐60dB@12.5KHz
≤‐70dB@25KHz
TransientSwitchACPR
±12.5kHz≤‐50dB
±25kHz≤‐60dB
