InstallationoftheSatelliteModule
Thesatellitemoduleandsatelliteantennaneedtobeinstalledbeforebasestations
can work as simulcast base stations. Put the antenna at places such as outdoor
whereitcanreceivebettersignalsfromsatellites.


 



* Align the satellite module with the slot and insert it into the base station (see
Fig.1‐②)
*Attachthesatelliteantenna,andputthemagneticblockatanoutdoorplacewhere
itcanbeexposedtodaylight.
Note: For detailed operation guides, refer to the software instruction.
SatelliteAntennaPort
Figure 5-Satellite Module
Figure 6-Satellite Antenna
