Specifications

7
RAK2287
7
20 W_DISABLE# NC No Connection
21 GND GND Ground
22 PERST# SX1302_RESET DI SX1302 reset input
Active high, ≥100ns for
SX1302 reset.
23 PERn0 RESET_GPS DI
GPS module ZOE-
M8Q reset inputs
Active low, Leave open if not used.
24 3.3Vaux 3V3 PI 3.3V DC supply
25 PERp0 STANDBY_GPS DI
GPS module ZOE-
M8Q external
interrupt input
Active low, Leave open if not used.
26 GND GND Ground
27 GND GND Ground
28 1.5V NC No Connection
29 GND GND Ground
30 SMB_CLK I2C_SCL IO HOST SCL
Connect to GPS module ZOE-M8Q’s
SCL internally. Leave open if not used.
31 PETn0 PI_UART_TX DI HOST UART_TX
Connect to GPS module ZOE-M8Q’s
UART_RX internally. Leave open if not
used.
32 SMB_DATA I2C_SDA IO HOST SDA
Connect to GPS module ZOE-M8Q’s
SDA internally. Leave open if not used.
33 PETp0 PI_UART_RX DO HOST UART_RX
Connect to GPS module ZOE-M8Q’s
UART_TX internally. Leave open if not
used.
34 GND GND Ground
35 GND GND Ground
36 USB_D- USB_DM IO
USB differential
data (-)
Require differential impedance of 90Ω.
37 GND GND Ground
38 USB_D+ USB_DP IO
USB differential
data (+)
Require differential impedance of 90Ω.
39 3.3Vaux 3V3 PI 3.3V DC supply
40 GND GND Ground
41 3.3Vaux 3V3 PI 3.3V DC supply
42 LED_WWAN# NC No Connection
43 GND GND Ground
44 LED_WLAN# NC No Connection
45 RESERVED HOST_SCK I/O Host SPI CLK
46 LED_WPAN# NC No Connection
47 RESERVED HOST _MISO I/O Host SPI MISO
48 1.5V NC No Connection
