RAK2287
3
1 Overview
1.1 Introduction
RAK2287 is a LoRa concentrator card with mini-PCIe form factor based on SX1302,
which enables an easy integration into an existing router or other network equipment
with LoRa Gateway capabilities. It can be used in any embedded platform offering a
free mini-PCIe slot with SPI or USB connection. Furthermore, ZOE-M8Q GPS chip is
integrated on board.
RAK2287 is a complete and cost efficient LoRa gateway solution offering up to 10
programmable parallel demodulation paths which are 8xSF5-SF12 LoRa demodulators,
8xSF5-SF10 LoRa demodulators, 500 kHz LoRa demodulator and (G)FSK
demodulator. It can detect at any time, any packet in a combination of 8 different
spreading factors(SF5 to SF12) and 10 channels, and demodulate up to 16 packets at
any time. It targets smart metering fixed networks and Internet-of-Things (IoT)
applications, covering up to 500 nodes per square kilometer in an environment with
moderate interference. Another feature is the integration of Ublox GPS module which
expands applications.
1.2
Main Features
 Compatible with Mini PCI-e Edition specification with heat sink.
 SX1302 base band processor emulates 8 x8 channel LoRa packet detectors, 8 x
SF5-SF12 LoRa demodulators, 8 x SF5-SF10 LoRa demodulators, one 125 /250 /
500 kHz high-speed LoRa demodulator and one (G)FSK demodulator .
 Built-in STM32L412K to convert SPI interface of SX1302 to USB2.0.
 Voltage of Mini PCI-e is 3.3 V, compatible with 3G/LTE card of Mini PCI-e type.
 Tx power up to 13.39dBm, Rx sensitivity down to -139dBm@SF12, BW 125 kHz.
 Supports latest LoRaWAN 1.0.2 protocol.
 Supports global license-free frequency band (US915).
 Supports optional SPI or USB interfaces.
 Built-in ZOE-M8Q GPS module
