Specifications

11
RAK2287
11
The table below lists the power supply range.
Input voltage at 3.3Vaux must be above the normal operating range minimum
limit to switch-on the module.
Symbol Parameter Min. Typical Max.
3.3Vaux
Module supply operating input
voltage
3.0 V 3.3 V 3.6 V
Table 6 | PowerSupply Range
2.11.4
Power Consumption
Table 7 | Power Consumption
2.11.5 RF Characteristics
The following table gives typically sensitivity level of the RAK2287 card.
Signal
Bandwidth/[KHz]
Spreading Factor
Sensitivity
/[dBm]
500
12 -133
500
7 -120
Table 8 | LoRa RF Characteristics
Note: The above parameters changes in difference region to compliance with the local
regulatory requirements, contract Rakwireless for detail.
3
Schematics Reference
RAK2287 card refers to Semtech's reference design of SX1302. The SPI interface or USB
interface converts SPI to USB2.0 by STM32L412Kx, and can be used on PCIE connector.
The next figure shows the minimum application schematic of RAK2287 card. You should
use it at least 3.3V/1A DC power, connect SPI interface or USB interface to the main
processor
.
Mode Condition Min AVG Max
Active-
Mode(TX)
The power of TX channel
is 13.39dBm and 3.3V
supply.
511mA 512mA 513mA
Active-
Mode(RX )
TX disabled and RX
enabled.
70mA 81.6 mA
101
mA
