Specifications

10
RAK2287
10
Tstg
Storage
Temperature
–40°C 85°C
Table 3 | Absolute Maximum Ratings
The product is not protected against overvoltage or reversed voltages. If
necessary, voltage spikes exceeding the power supply voltage specification,
given in table above, must be limited to values within the specified boundaries
by using appropriate protection devices.
2.11.2
Maximum ESD
The table below lists the maximum ESD.
Parameter Min Typical Max Remarks
ESD_HBM
1000V
Charged Device Model
JESD22-C101 CLASS III
ESD_CDM
300V
Charged Device Model
JESD22-C101 CLASS III
Table 4 | Maximum ESD Ratings
ESD HANDLING: Although this module is designed to be as robust as possible,
electrostatic discharge (ESD) can damage this module. This module must be
protected at all times from ESD when handling or transporting. Static charges
may easily produce potentials of several kilovolts on the human body or
equipment, which can discharge without detection. Industry-standard ESD
handling precautions should be used at all times.
2.11.3
Operating Conditions
The table below lists the operation temperature range.
Parameter Min. Typical Max. Remarks
Normal operating
temperature
–40°C +25°C +85°C Normal operating temperature range
Table 5 | Operation Temperature Range
Note: unless otherwise indicated, all operating condition specifications are at
an ambient temperature of 25
° C. Operation beyond the operating conditions
is not recommended and extended exposure beyond them may affect device
reliability.
