GWF-3M05-33-T, for 3.3+/-5%VDC, the long pins are at the same side with the shield case.
GWF-3M05-33-B, for 3.3+/-5%VDC, the long pins are at the opposite side with the shield case.
GWF-3M05-33-C, for 3.3+/-5%VDC, Soldered with 6 pin connector.
GWF-3M05-50-T, for 5.0+/-5%VDC, the long pins are at the same side with the shield case.
GWF-3M05-50-B, for 5.0+/-5%VDC, the long pins are at the opposite side with the shield case.
GWF-3M05-50-C, for 5.0+/-5%VDC, Soldered with 6 pin connector.
3. Agency Approval
Agency Approval
FCC Part15 undergoing
CE √
RoHS √
4. Environment
4.1 Temperature
4.1.1 Operating Temperature
Continuous reliable operation in ambient temperature: 0ºC to +50ºC.
4.1.2 Storage Temperature
The product is not damaged or degraded when keeping in -20ºC to +85ºC.
4.2 Humidity
4.2.1 Operating Humidity Conditions
The product is capable of continuous reliable operation when subjected to relative humidity
in the range of 20% to 80% (non-condensing).
4.2.2 Non-Operating Humidity Conditions (including warehouse)
The product is not damaged or degraded when kept in the relative humidity range
from 20% to 80%.
