SAMSUNG POWERED WIFI SPEAKER DOCK MODEL:CAW-03012 PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE OPERATION AND KEEP IT FOR FUTURE REFERENCE
IMPORTANT SAFETY INSTRUCTIONS CAUTION: TO REDUCE THE RISK.OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK}. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. A A 'llle llghll119 llah wMI envwhead aymbol, wMlln on 9qul ....ral lr1ilngll, 19 lnl8ndld tD llort u.. to the p....nce tlf unli,sul•..,•..,... voltmgo" within th• product._ encl....,,.., thet moy be of autllclont mau- to conetlluta • rtek of el-. Th• """lomellon paint within mn oquHat.nl tr1ongl• I• Int. to a1..
LOCATION OF CONTROLS MAIN UNIT: TOP VIEW 1 2 3 4 5 FRONT VIEW 6 7 8 9 REAR VIEW 10 11 1. Play/Pause (WiFi Pairing) Button 12 13 8. AUX IN Indicator 2. Previous (Volume Down) Button 9. SD/USB Indicator 3. Next (Volume Up) Button 10. SD Card Slot 4. Mode (Power On/Off) Button 5. Battery Indicator 11. AUX IN Jack 6. WiFi Indicator 12. USB Port 7. Bluetooth Indicator 13.
Specification Power supply.........................................................................................9.5V 2.2A Audio output...................................................................................................6WX2+10W (RMS) Running Time.......................................................................around 3.2 hours(with 50% volume) Recharging Time..................................................................................................
RECHARGING During playing, press the battery indicator button to display the battery level. Battery Indicator Button The battery indicator will flash blue during low battery level. Battery Indicator Using the supplied Adapter to recharge through the DC IN jack at the rear of the main unit. The red indicator will light up when charging, it will turn blue after fully charged.
BLUETOOTH OPERATION Pairing the speaker with Bluetooth devices (phone or music device) 1. Press and hold the M button to turn on the unit. 2. Press the M button repeatedly to turn to Bluetooth mode, the Bluetooth indicator on front of the unit will light up and blink, and a tone sounds, now it is entering pairing mode. 3. Activate the Bluetooth function on your Bluetooth device (phone or music device). Please refer to the manufacturer’s instructions of your device. 4.
AUX IN OPERATION 1. Connected the external audio device to the unit by an audio connection cable with 3.5mm stereo mini jacks as: ~ Insert one end to the Phone; Line Out or AUX Out Jack on the external audio device. ~ Insert the other end to the AUX IN jack on the rear of the main unit. MP3 Mobile Phone Connect to the Phones; AUX Out; Line Out Jack of the external devices (Such like MP3 Player; cell phones; iPod/iPad ... etc) To AUX IN jack on the rear of the unit (Audio Connection Cable supplied) 2.
USB/Sd OPERATION NOTE: Only the USB or SD Card inserted to the unit can the USB/SD mode be selected. The latter one inserted to the unit will be played first. REAR VIEW OF THE UNIT USB Sd 1. Insert the USB device or SD memory card into the USB port/card slot as shown above figure. 2. Press and hold the M button to turn on the unit. 3. Press the M button repeatedly to turn to USB/SD mode, the USB/SD mode indicator on front of the unit will light up. 4.
Setup PREPARATION Before connecting the mobile phone with the unit, search the VARO WIFI CONTROLLER from network by the following website: Android: http://fir.im/bvaro iOS: http://fir.im/varo VARO WIFI CONTROLLER Fig. 1 Download and install the App and set the language of mobile phone to English. The App icon will appear like the Fig.1 after successful installation. NOTE:Please make sure that there is no AUX IN cable plugged in AUX IN jack.
Setup Select the same WiFi (router source) as the phone connected and tap LOGIN on Fig.E. Press and hold the button on the unit as instructed on Fig.F and tap Next to continue. Wait unit the progress bar reach 100% as instructed on Fig.G. Select to add another speaker or play music after successful connection as Fig.H. Fig.E Fig.G Fig.F Fig.
Setup Wait unit the progress bar reach 100% as instructed on Fig.G. If it displays like Fig.M, tap Try Again to repeate the above stated steps to reconnect. If it does not fail to connect, continue to set the SPEAKER LOCATION, tap Custom...column on Fig.N to rename the speaker location. Input the name and confirm on Fig.O. Fig.M Fig.O Fig.
Glance at The Function of Each Icon On SPEAKER CONTROLS page (Fig.P), tap to return to home page. Tap Rename, browse the Speaker Info and Preset Content. Tap to Add a New Speaker to add more speaker as onscreen instructions. Tap Pause All to pause playing on all speakers, tap again to resume play all speakers. Tap volume level bar to adjust the volume, tap STEREO icon to set to LEFT channel or RIGHT channel. Speaker Info Page Home Page Fig.P on SPEAKER CONTROLS page to set solo or multi mode.
Guide of Using App Functions On Home Page, tap Search to search the desired music shown on the below pictures. Home Page On Home Page, tap Favorites to to listen your favorite music, on music playing page, icon to add songs to Favorites. tap the icon to add songs to My Playlist, tap the On Home Page, tap My Music to listen from native music, My Playlist or Recently Played music. On Home Page, tap TuneIn to listen online radio, or other programes.
Guide of Using App Functions On Home Page, tap Sportify to listen music. On Home Page, tap Add More Services to add the desired online programs platform. Tap Line in, Bluetooth, USB Devices or Optical to switch function mode on Fig.S. Tap Setings to check the Version and Feedback information on Fig.T. Sportify Fig.S Fig.T NOTE: Other detail functions like adding, cancel, delete, manage...customize, etc. can be operated according to the onscreen instructions.
FAQ Q: Can't stream music to the device? A: Make sure your phone or PAD are in the same Wi-Fi network as your device. If you use 3rd. music APP, please check if the APP supports Airplay, DLNA or Qplay protocol. Q: Can the APP system be controlled independently by two different phones/tablets at the same time or can it only be controlled with one? A:It can be controlled by different phones / tablets. Q: Can I play my MP3 music collection on the iphone? A: Yes.
