5.2 Server(Indoor)antenna

5.3 AuthorizedKittingOptions
OutdoorDefaultAntenna&CableKitOptions
1. Kit9‐5050
OutdoorYagi9dbiAntenna&50’5DCoaxialCable
IndoorDefaultAntenna&CableKitOptions
1. Kit5‐0
IndoorWhip5dbiAntenna
OutdoorAntenna&CableKitOptions
2. Kit11‐7550
OutdoorYagi11dbiAntenna&75’5DCoaxialCable
3. Kit11‐10050
OutdoorYagi11dbiAntenna&100’5DCoaxialCable
4. Kit10‐75400
OutdoorPanel10dbiAntenna&75’400CoaxialCable
5. Kit10‐100400
OutdoorPanel10dbiAntenna&100’400CoaxialCable

6. Kit10‐7550
OutdoorPanel10dbiAntenna&75’5DCoaxialCable
7. Kit10‐10050
OutdoorPanel10dbiAntenna&100’5DCoaxialCable
8. Kit9‐50400
OutdoorYagi9dbiAntenna&50’400CoaxialCable
9. Kit9‐5050
OutdoorYagi9dbiAntenna&50’5D
CoaxialCable
10. Kit9‐75400
TheWhipAntenna
Thewhipantennaisanomni‐directionalantennawitha360degreereach.It
isdesignedtodistributethesignalfromthecenteroftheaffectedarea.
Typicallyitisconnecteddirectlytothebooster.
TheOmniAntenna
Theomniantennaisanomni‐directionalantennawitha360degreereach.It
isdesignedtodistributethesignalfromthecenteroftheaffectedarea.
Typicallyitisinstalledinafalseordroppedceiling.
ThePanelAntenna
Thepanelisadirectionalantennawitha120degreereachandisdesignedto
distributethesignalfromaperimeterwallorceiling.
