Thank You

Thank you for choosing the Meeteasy MVOICE 8000 series conference speakerphone. In this

User Guide, you will find everything you need to quickly set up, use and manage your new

conference speakerphone.

Overview

MVOICE 8000 series speakerphone is specially designed for efficient collaboration in large

conference rooms, to fulfill the customers’ increasing demand for web-conferencing,

hands-free calls and teleconferencing. They can be connected to a PC, laptop via USB, or

mobile phone via Bluetooth, and also work great with PC-based communication software.

With full bandwidth frequency response and advanced audio processing technologies,

MVOICE 8000 series speakerphones can handle any audio requirement, whether that is the

conference call, or listening to your favorite music.

Highlights and features

●

Connect to PC via USB.

●

Connect to mobile device via Bluetooth.

●

Three built-in 360° coverage microphones.

●

Hi-Fi sound quality.

●

DSP noise and echo cancellation.

●

Ultra-low power consumption.

Connecting to PC or laptop

Plug and play, simply connect your MVOICE to the USB port on your PC or laptop with USB

cable. Support Windows XP, Windows Vista, Windows7/8/10 etc.

Attention: the MVOICE works excellently in web-conferencing via Skype or other VoIP

software. The PC can automatically recognize the MOVICE device, but you may need to

choose MEETEASY USB AUDIO in application software. For example, you would need to

choose MEETEASY USB AUDIO in Skype audio setting section.

Connecting to mobile device

Press and hold (2secs) the Bluetooth button until the light flashes blue. Enable Bluetooth

on your mobile device, and select “Meeteasy” from the list of available Bluetooth devices.

The light turns solid blue when the connection is established.

Turn off the Bluetooth function

Press and hold (2secs) the Bluetooth button and then the Bluetooth function will be

closed.

Answer /Reject a call via Bluetooth

Short press to answer the incoming call, long press to reject the incoming call. When in a

connected call or dialing, short press this button could hang up the call.

Mute the speakers

Press the button can mute the speaker, the button turns red.

Mute the microphones

Press the button can mute the microphones all, the button turns red.

Increase the volume

Press the button can increase the volume level.

Decrease the volume

Press the button can decrease the volume level.

ON/OFF button

Turn the button to ON side, the MVOICE unit can be powered by built-in battery.

ON/OFF state will not affect the USB charging and USB connection to the PC.

Separate microphone selection

For large group meeting, all three microphones open can make proper audio reception of

participants from all angles.

Charging safety

Charging starts once the MVOICE unit is connected to PC.

Sound pickup range

In normal room conditions, the reception distance can reach to 5 meters. Built-in

three microphones provides with 360-degree coverage. The sound pickup range may

differ depending on the operating environment and conditions.

Guide for external microphones

For the model MVOICE 8010 EX-B, two external microphones (EX-MIC) are provided within

the package for upgrading to larger conference situation applications.

Connect microphone wire to MVOICE 8010 EX-B unit and thread through channels at

the unit back side.

Position EX-MIC for best voice pick up.

3) Using the external microphones.

A) The EX-MIC is default ON when the MVOICE unit is powered-on.

B) Press the button on the EX-MIC can mute all the

microphones, the indicator light turns red.

C) Press the button again on the EX-MIC can resume all the

microphones, the indicator light turns green.

Screen

...........................................

....

6ft

(2m)

6ft
