G S - S B 106 BLUETOOTH SOUNDBAR Instructions Guide
Contents Controls And Functions -----------------------------------------1 What’s In The Box? ---------------------------------------------- 4 Support ------------------------------------------------------------- 5 User Manual ------------------------------------------------------- 6 Using the AUX IN Cable -------------------------------------- 6 Using the ARC Input ------------------------------------------- 7 Using the Optical Input --------------------------------------- 8 Using the MP3 Link Connection (
Controls And Functions Side View/Control Buttons 1.Power ON/OFF 2.Volume +/Next 3.Volume -/Prev 4.Mode Back View 5.DC Power Input 6.AUX-IN Input 7.LINE-IN Input 8.OPTICAL-IN Input 9.USB-IN Input 10.
Remote Control 10. Power On/Off Switch the unit between on and Standby mode 10 18 11. Volume + Press to increase the volume 12. Back Step 11 12 19 13 Use in AUX or Bluetooth mode to go back a track. 13. Play/Pause 14 Press to play and pause 14. Volume 15 20 15. Bass Increase Press to increase the bass 16 17 Press to decrease the volume 21 16. EQ Press the button to adjust the equaliser. Press and hold the button to turn the soundbar LED light on and off. 17.
Controls And Functions Using the Remote Control The remote control sensor at the front of the soundbar is sensitive to the remote control’s commands up to a maximum of 8 metres away and within a maximum arc of 30 degrees. Please note that the operating distance may vary depending on the brightness of the room.
Box Contents 1. GS-SB106 Soundbar 2. Remote Control 3. Power Adapter x 1 4. AUX IN Cable 5. Optical Cable 2.Remote Control 4 6. User Manual Wha t’s 2 x Screws In 2 x Expanded Rubber Stopper The Box ? 1. GS-SB106 Soundbar 7. 3.5mm to 3.5mm Line In Cable 8. 9. 4. AUX IN 3. Power Cable Adapter 5. 3.5mm to 3.5mm Line In Cable 6.
Support Thank you for your purchasing the GS-SB106 Soundbar. Please follow the guidance of the user manual to set up your new purchase and begin enjoying its features.
Instructions Guide Using the AUX IN Cable Use the AUX Stereo Audio Cable (included) to connect the TV’s stereo AUX (L/R) audio output socket. Connect the audio output cable of the soundbar via the ‘AUX’ input sockets of the unit. Then press MODE on the remote control (Rem.18) or press the Mode button on the unit to scroll to the AUX IN function.
Using the ARC Input You will need: An audio source with an ARC Audio Output and a ARC Audio cable (not included). Connect the ARC Audio cable to the ARC output on the audio source and to the ARC Input on the soundbar. Press the POWER button on the soundbar or POWER button directly on the remote control (Rem.10) to switch on the unit. Press the MODE button on the remote control (Rem.18) to switch to ARC mode or select the Mode button on main unit repeatedly to select the ARC mode.
Instructions Guide Using the Optical Input You will need: An audio source with an Optical Audio Output and a Digital Optical Audio cable (included). Connect the Digital Optical Audio cable to the optical output on the audio source and to the Optical Input on the soundbar. Press the POWER button on the sound bar or POWER button directly on the remote control (Ref.10) to switch on the unit. Press the MODE button on the remote control (Rem.
Using the MP3 Link Connection (Line In) Plug one end of a 3.5mm to 3.5mm Line In cable (included) into the Line In port on the unit. Before use, disconnect any cables connected to the Stereo RCAInputs. Plug the other end of the cable into the audio output/ headphone output on an MP3 player or other audio source. Press the Power button on the soundbar or POWER button directly on the remote control (Rem.10)to switch on the unit.
Instructions Guide Connecting to the Mains Supply Ensure that the power supply voltage is in the voltage of 100V~240V. This unit is designed to use adapter. Connecting the unit to any other power source may cause damage to the unit. Unwind the mains cable to its full length. Connect the mains plug to a mains socket. Make sure the mains plug is fully inserted into the mains socket. Connect the adapter to the unit via the DC input Socket.
Instructions Guide Using the Bluetooth Operation Pairing a Bluetooth Device for the First Time Press the POWER button on the unit or the POWER button on the remote control (Rem.10) to switch on the unit. Select and press the MODE button repeatedly on the remote control until in Bluetooth mode (Rem.18)or press the Mode button repeatedly on the sound bar to enter Bluetooth mode. Using the native controls on your Bluetooth device, select the “SB-94” in your Bluetooth settings to pair.
Playing Audio Wirelessly Follow the instructions for pairing a Bluetooth device. Use the native controls on the connected Bluetooth Device to select a track. To Play/Pause the track or Skip Forwards/Backwards to a selected track, use the remote control (Rem.12,13,19). Audio played through the connected Bluetooth device will now be heard through the speakers. Using the USB Operation Insert USB to Play Music Automatically.
Troubleshooting If the soundbar does not work properly as desired, please check the following. Malfunction Possible causes/measures No power / function Check whether the power is switched on or off at the wall. Check whether the power adaptor is properly connected to power outlet or not. No sound Check whether cables are properly installed. If they are, please try alternative cable to connect to your TV if possible. Check unit is out of standby and in mode.
Specifications Specifications Power Supply DC 24V Power Output (RMS) 2x15W+50W Speaker Size 2.25 inch x2+3.5inch x2 Working environment (Temperature) -10~ + 55C Relative Humidity 5% ~ 90% Frequency Response 50Hz~18KHz Bluetooth V5.0 Dimension (LxWxH) L94 x D 14.7 x H 7.
Quick System Installation Guide Place the paper guide on the wall where you want to hang the soundbar. Locate the screw holes on the paper guide and mark a point with a pencil. Verify with a level gauge that the inclination angle of the soundbar is zero degrees. Make the holes with the corresponding drill bit according to the type of wall.
1. 2. 3. 4. 5. 6. Read these user manual. Keep these user manual. Heed all Warnings Follow all instructions Do no clean the apparatus near or with water Do not block any ventilation openings. Install in accordancewiththemanufacturer’sinstructions 7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 8.
FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
